Complete Indoor Farming Solution
The Smart Vertical Microgreens Growing System is a compact, sensor‑driven indoor farming solution designed to enable high‑quality, pesticide‑free microgreens production in a fully controlled environment. Unlike conventional systems that focus only on lighting or hydroponics, this system integrates production, environmental control, automation, and performance evaluation into a single unit – making it suitable for urban farming, research, and commercial applications. This approach addresses a key gap identified across multiple research studies, where no single system integrates growth, control, and post‑harvest considerations together.
Core Capabilities
Everything you need for clean energy performance — engineered and field-tested.
Temperature Control
- Continuous monitoring
- Cooling fan auto ON if limit exceeded
- Ensures optimal growth range
Lighting Control
- LED grow lights (Red + Blue spectrum)
- Programmable day/night cycles
- Optional UV‑A enhancement
Intelligent Irrigation
- Manual, Timer‑Based, or Moisture‑Based (Smart) Modes
- Soil moisture sensing prevents over‑irrigation
- Pump & valve auto‑control
Environmental Monitoring
- Temperature & humidity sensors
- Soil moisture display
- Real‑time control panel
System Configuration
| Parameter | Specification |
|---|---|
| System Type | Vertical Indoor Microgreens Growth Chamber |
| Structure Size | Approx. 750 × 550 × 1200 mm |
| Layers | Multi‑layer tray system (3 levels) |
| Structure Type | Enclosed controlled cabinet |
| Material | Aluminum / SS / Powder‑coated MS |
| Installation | Floor‑mounted compact unit |
Lighting System
| Parameter | Specification |
|---|---|
| Light Type | LED grow lights (Red + Blue spectrum) |
| Optional | UV‑A enhancement |
| Placement | Mounted under each layer |
| Light Cycle | Controlled via timer (e.g., 18h OFF / 6h ON configurable) |
| Purpose | Photosynthesis + growth optimization |
Irrigation & Water System
| Component | Specification |
|---|---|
| Water Source | Bottom reservoir tank |
| Distribution | Pump‑based / spray system |
| Control | Automated valve‑based irrigation |
| Irrigation Type | Mist / controlled watering |
Airflow & Environmental Control
| Parameter | Specification |
|---|---|
| Ventilation | Exhaust fan system |
| Function | Temperature & humidity control |
| Airflow Type | Continuous circulation |
| Placement | Rear / top‑mounted airflow system |
Environmental Monitoring
| Parameter | Function |
|---|---|
| Temperature | Maintains optimal growth range |
| Humidity | Controls moisture environment |
| Soil Moisture | Determines irrigation need |
| Display | Real‑time monitoring panel |
Smart Automation Logic
| Mode / Feature | Description |
|---|---|
| Temperature Control | System monitors continuously; if temperature exceeds set limit → cooling fan ON, else OFF. |
| Lighting Control | Automated timer‑based lighting cycle (e.g., 18h OFF / 6h ON, configurable). |
| Irrigation – Manual Mode | User‑controlled ON/OFF. |
| Irrigation – Timer Mode | Irrigation at fixed intervals. |
| Irrigation – Smart Mode | Checks soil moisture periodically; if below threshold → pump ON, valve opens, water sprayed; auto OFF after set duration. |
Growing Capacity & Crops
| Parameter | Value |
|---|---|
| Trays per Layer | 2 |
| Total Capacity | 5 compartment 10 trays |
| Crop Cycle | 7–14 days |
| Crop Types | Microgreens (sunflower, radish, wheatgrass), leafy greens (lettuce, spinach), herbs (basil, coriander) |
Perfect For
A versatile automated farming chamber, ideal for multiple applications and users.
Urban Farming
Fresh produce in limited space
Research Labs
Controlled environment studies
Commercial Growers
High‑quality microgreens
Educational Institutions
Hands‑on agri‑tech learning
Restaurants & Chefs
Fresh, chemical‑free greens
Safety, Benefits & Power
| Feature | Description |
|---|---|
| Hygiene & Safety | Fully enclosed dust‑free chamber, food‑grade surfaces, low‑voltage safe operation |
| Key Benefits | Year‑round farming, 80–90% water savings, faster cycles, chemical‑free, space‑efficient |
| Power Requirements | Low voltage DC system; adapter powered (solar optional); energy‑efficient LED + pump + fan |
Optional Upgrades
| Add‑on | Benefit |
|---|---|
| IoT‑based Remote Monitoring | Real‑time data, alerts, analytics |
| AI‑based Crop Advisory (AgroSense) | Yield optimization, growth recommendations |
| UV‑A Lighting Enhancement | Increased nutritional value, pathogen control |
| Data Logging for Research | Exportable growth data for studies |
| Solar Power Integration | Off‑grid operation |
Health Benefits for End Customers
Supercharge your daily nutrition with fresh, locally grown microgreens.
Core Nutrition & Protection
- High Nutrient Density: Contains 30–40x more vitamins & minerals
- Boosts Immunity: Rich in vitamin C, E, and antioxidants
- Supports Heart Health: Reduces cholesterol & improves cardio function
- Helps Manage Diabetes: Low glycemic, supports blood sugar control
- Anti-Inflammatory: Reduces inflammation and supports overall wellness
- Improves Brain Function: Antioxidants protect brain cells and enhance focus
- Rich in Antioxidants: Fights free radicals and slows aging
Wellness & Vitality
- Good for Eye Health: Contains carotenoids like lutein & beta-carotene
- Supports Bone Strength: Source of calcium, magnesium, and essential minerals
- Aids Digestion: High fiber content improves gut health
- Weight Management: Low calorie, high nutrition food
- Detoxifies the Body: Helps remove toxins naturally
- Skin & Hair Health: Nutrients support glowing skin and stronger hair
- Chemical-Free & Safe: Grown in a controlled environment without residues
